| トリガ・モード | Auto trigger, manual trigger, bus trigger, Handler trigger, foot switch trigger |
|---|
| ストレージ | 30 sets of instrument parameters |
|---|
| 測定速度 | |
|---|
| Single board | 100 times / sec, 40 times / sec, 2 times / sec |
|---|
| 6 boards | 600 times / sec, 240 times / sec, 12 times / sec |
|---|
| テスト端子 | Four-terminal test |
|---|
| コンパレーター | Comparison boundaries are set separately for each test channel |
|---|
| 測定アイテム | DC resistance, temperature | DC resistance |
|---|
| 測定結果表示 | Simultaneous display the test results of 16 channels and support page turning |
|---|
| 測定モード | Stand-alone, scanning |
|---|
| 温度補償 | ○ | — |
|---|
| 抵抗測定範囲 | 10μΩ — 200kΩ |
|---|
| 抵抗測定基本確度 | 0.05 % |
|---|
| 抵抗測定レンジ | Auto and manual (200mΩ, 2Ω, 20Ω, 200Ω, 2kΩ, 20kΩ, 200kΩ) |
|---|
| 温度センサ・タイプ | PT500 platinum resistance, PT100 platinum resistance, analog voltage input Temperature test range | — |
|---|
| 温度測定確度 | |
|---|
| PT100, PT500 | 0.3%*measured value ±0.5℃ | — |
|---|
| Analog | ±1%Rd ± 3mV | — |
|---|
| スキャナー・チャンネル数 | 15 channels/boards, and up to 6 boards and 90 channels can be inserted. The board channel is for scanning test, and it is synchronous test between the test boards. |
|---|
| 測定端子の選択 | Arbitrary configuration between channels (programmable) |
|---|
| 測定電流 | ≤100mA |
|---|
| ショート補正 | Support full-scale short-circuit clearing for all channels |
|---|
| リミット・モード | ABSDev、ABS、% |
|---|
| 温度測定範囲 | |
|---|
| PT100, PT500 | -10℃ — 99.9℃ | — |
|---|
| Analog | 0V — 2V | — |
|---|
